WELD-M-15KW with Slot Automatic walking style tarpaulin welding machine

WELD-M-15KW with Slot

HF wave welding machine: Welds PVC biogas tanks, water tanks, kids’ swimming pools. Also for automotive tarpaulins, tent fabrics, film curtains, sunshade/advertising cloths, low-frequency PVC cloth & soft PVC plastics—delivering efficient high-frequency welding/splicing.

Quantity

Contact Now

add to cart

Model	WELD-M-15KW With solt	WELD-M-25KW With solt
Model	WELD-M-15KW With solt	WELD-M-25KW With solt
Suitable Welding Area	30MM*1000MM	50MM*1000MM
Voltage	AC3∮ 380V 50HZ	AC3∮ 380V 50HZ
Control Method	PLC/man-machine interface	PLC/man-machine interface
PLC	Delta	Delta
Servo	Delta	Delta
Oscillating Frequency	27.12Mhz	27.12Mhz
Maximum working pressure	1000KG	1500KG
Oscillator	8T85RB	8T25RA
Groove Size	500*200MM	500*200MM
Alignment System	Imported Rail	Imported Rail
Rectifier	Silicon Diode	Silicon Diode
Pressurization Method	Airtec	Airtec
Machine Color	White / or Customized	White / or Customized
Effective Track Length	According to customer requirements	According to customer requirements
Contactor and Switch	CHNT	CHNT
Time Relay	OMRON	OMRON
Pneumatic Components	Airtec	Airtec
